Power : 1hp
Voltage : 220-240V
Frequency : 50Hz
Min.Flow : 0.6m³/h
Max. Flow : 10m³/h
Min.Head : 2.8m
Max. head : 9m
Inlet/outlet port diameter : ½”1
Speed : 2850RPM
Max. liquid temperature : ℃35
Max. Ambient temperature : ℃40
Working Pressure : 0.9BAR
solid passage diameter : 4mm
max immersion depth : 5m
max dry running tim : 30seconds
Protection level : IP68
Insulation Class : CLASS B
Pump housing material : PP
Motor housing material : PP
Mechanical seal material : C/G
Motor protection : Thermal protector
Coil winding material : COPPER
Impeller material : PPO
shaft material : SS304+45#
Weight : 4.7kg
